Connector ports for test meter leads include the ground lead port, channel one test lead port and channel two test lead port. The micro SD card port holds the micro SD card that contains the MODIS Ultra software. Use only the correct AC adapter provided with the MODIS Ultra. The power supply port is used to connect the AC/DC power supply. The power indicator illuminates when power is being supplied to the tool. Indicators and connectors are on the top panel. Replace the battery cover onto the housing and snug up the screws to hold the cover in place. Then slide the battery up to lock into place. Align the tabs on the sides of the battery compartment with the slots on the new battery.
Then pull on the inner edge of the cover and lift. To install the battery pack, loosen the two screws that retain the battery compartment cover. This training module covers the basic setup and controls.īefore operating or maintaining MODIS Ultra, read the safety instructions and user manual carefully, paying extra attention to the safety warnings and precautions. Snap-on ® Training Solutions ® helps you get the most out of your MODIS Ultra™ diagnostic tool. For more information about the latest software coverage and features, or available software programs, contact a participating Snap-on Franchisee, other sales representative, or visit. New feature highlights include a new live vehicle battery voltage reading, and new updates on the "Smart Data" graph view and the "Previous Vehicles and Data Screen".įor specific coverage and features by platform, refer to the vehicle coverage guide at. New coverage highlights include 2021 model year updates for all available makes and expanded code scan and clear codes for model year 2022. New features and coverage give technicians the opportunity to take advantage of state-of-the-moment diagnostic solutions.
With the latest release, innovative diagnostic tool capabilities can drive technician confidence, knowing they are ready to serve customers with unparalleled depth in general and collision repair coverage, the company says. Professional service technicians can bring out the best in their Snap-on Diagnostic platforms when they upgrade to the newest version of software, which is available now.
